Elite4

We help configure and deploy Elite4, tailored to your production needs

Core Solution

Core Solutions

Four integrated capabilities built for demanding multicolor production environments — from variable data and code verification to high-speed CMYK inkjet output.

High Speed Multicolor Inkjet System

Purpose-built for demanding production environments. Industrial piezoelectric printheads (normal service life of 3 years or more) deliver consistent, high-quality multicolor output at speeds up to 60 m/min with minimal downtime...

Variable Data Printing Software

Powered by Tracesci VDP Software — print barcodes, QR codes, dates and times, work group numbers, counters, graphics, tables, and databases in real-time. Printheads can be combined arbitrarily with multiple documents printed simultaneously at full production speed...

Track and Trace Solution

Integrated real-time printing of serialised codes ensures every item is uniquely identified and trackable across the supply chain. Supports full product authentication, anti-counterfeiting, and compliance workflows with centrally controlled print management...

Authenticate Your Product

Leverage the Elite4's multicolor CMYK inkjet capability to print overt and covert security marks, QR codes, and unique identifiers directly onto packaging at full line speed — enabling end-to-end product authentication from factory to consumer...

CMYK UV & Aqueous Inks

Dual ink compatibility — CMYK UV curable and aqueous systems — with continuous ink supply delivering to up to 4 printheads simultaneously. Automatic ink type identification with low ink level alarm. Black, spot colour, and security ink options for pharma, packaging, labels, and security applications...

Easy Operation & Quick ROI

15-inch industrial-grade capacitive touchscreen (1280×800) running Windows for intuitive operation. PLC, RS485, RS232, WAN and LAN connectivity for seamless system integration. Designed for swift installation and rapid start-up, ensuring fast return on investment...

Technical Specifications

Technical Specifications

Industrial piezoelectric printheads with CMYK UV & aqueous inks for high-speed multicolor output at up to 1200 DPI.

Specifications
Printhead Type
Industrial Piezoelectric Printheads
Printing Speed
Up to 60 m/min
Printing DPI
300–1200 DPI Adjustable
Printing Width
1–33.8 mm
Printing Method
Downspray
Printing Distance
2–4 mm
No. of Printheads
Up to 4
Specifications
Consumable
CMYK UV Ink / Aqueous
Ink Supply
Continuous; supplies up to 4 printheads simultaneously. Auto ink-type ID & low-level alarm.
Feed Width
45–300 mm
Feed Thickness
Max 5.0 mm
Dimension
2503 × 750 × 805 mm
Weight
870 kg
Power
6 KW / 220V 50Hz/60Hz
Specifications
Controller
15" Industrial Capacitive Touchscreen
1280×800 resolution
OS
Windows
Connectivity
PLC, RS485, RS232, WAN, LAN
USB Ports
4
Language
English
Operating Temp.
15°C – 40°C

Built for speed & multicolor precision

The Elite4 is engineered to deliver exceptional multicolor throughput at up to 60 m/min without sacrificing print quality — even in high-demand continuous production environments running CMYK UV or aqueous inks.

  • Suited Best For :

  • Paper & Coated

  • Plastics & PVC

  • Cartons

  • Blister Packs

  • Pharma & Healthcare Packaging

  • Secure Substrates

  • Labels & Flexible Packaging

Ancillary Equipment

Ancillary Equipment

Complete your production line

Ancillary equipment available at additional cost — configure the exact system your production environment demands.

Print Head Guarding
Protection & safety enclosure
UV Dryer
Instant UV ink curing
Web Cleaner
Inline substrate cleaning
Web Guide
Precision web alignment
Anti-Static Bars
Static elimination system
Sheet Feeder–Stacker
Automated feed & collection
Reel to Reel System
Continuous roll media handling
Corona Treater
Surface treatment for adhesion
Inspection System
100% inline print inspection
Numeric Rejection
Automated defect rejection

Working Environment

Working Environment

Optimised for consistent performance

15–40°C
Operating Temperature

The Elite4 operates across a wide ambient temperature range of 15–40°C, ensuring reliable ink viscosity and printhead performance in diverse factory and production environments.

5–45°C
Storage Temperature

Storage environment rated at 5–45°C ensures the Elite4 can be safely stored and transported across varying climate conditions without risk to print head or electronic components.

3+ Years
Printhead Service Life

The Elite4's industrial piezoelectric printheads are rated for a normal service life of 3 years or more, delivering long-term reliability and reduced cost of ownership across continuous multicolor production runs.

Man and woman working together
Get In Touch
Ready to shift into
production mode?

Tell us about your production requirements and we'll configure the ideal Elite4 system for your line — including any ancillary equipment needed for a complete multicolor inkjet solution.

High speed multicolor inkjet — up to 60 m/min
CMYK UV cured & aqueous ink compatibility
Tracesci VDP software — barcodes, QR, serialisation
Track & trace and product authentication built-in
Full ancillary equipment range available

Multicolor Variable Data Printing & Product Authentication

Elite4 delivers high-speed CMYK variable data printing with barcode, QR code, serialisation, authentication, and track & trace capabilities — supporting production speeds up to 60 m/min with industrial piezoelectric printheads and centralized multi-head control.
