Industrial Inkjet System
Purpose-built for 24×7 industrial production environments. Robust Piezo DOD print head technology delivers consistent, high-quality output across demanding continuous-run operations with minimal downtime.. ...
Razor6
Precision-engineered Piezo DOD technology delivering
Technical Specifications
Technical Specifications
Precision-engineered with Piezo DOD technology and UV curable aqueous inks for consistent high-performance output.
Specification
Print Heads
Piezo DOD Technology Industrial Printhead
Print Width
Multiple of 54.1 mm (2.1")
Resolution
600×600, 600×300 dpi and more
Drop Volume
Binary: 5pl / Greyscale: 5–15pl
Specification
Compatible Inks
UV Curable, Aqueous
Ink Tank
0.5L / 1L
Colour Options
Black, Spot, Security Inks
Substrates
Paper, Coated, Plastics, PVC, Cartons, Blister etc.
Specification
VDP Software
Tarcesci RapidPro
Temperature
20–28 °C
Humidity
40–60%, Non-Condensing
Speed
Up to 150 mtr/min (resolution dependent)
Built for speed & precision
The Razor6 is engineered to deliver exceptional throughput without sacrificing print quality — even in the harshest 24×7 continuous production environments.
-
Suited Best For :
-
Paper & Coated
-
Plastics & PVC
-
Cartons
-
Blister Packs
-
Security Substrates
Ancillary Equipment
Ancillary Equipment
Complete your production line
Ancillary equipment available at additional cost — configure the exact system your production environment demands.
Print Head Guarding
Protection & safety enclosure
UV Dryer
Instant UV ink curing
Web Cleaner
Inline substrate cleaning
Web Guide
Precision web alignment
Anti-Static Bars
Static elimination system
Sheet Feeder–Stacker
Automated feed & collection
Reel to Reel System
Continuous roll media handling
Corona Treater
Surface treatment for adhesion
Inspection System
100% inline print inspection
Numeric Rejection
Automated defect rejection
Working Environment
Working Environment
Optimised for consistent performance
20–28°C
Temperature Range
Maintain ambient temperature between 20–28°C for optimal ink viscosity and print head performance throughout extended production runs.
40–60%
Relative Humidity
Non-condensing humidity range of 40–60% RH prevents ink drying issues and ensures consistent drop formation from Piezo DOD print heads.
24×7
Continuous Operation
The Razor6 is engineered for round-the-clock industrial production with robust print head durability, minimal maintenance cycles, and quick-access ink systems for non-stop throughput.
Get In Touch
Ready to shift into
production mode?
production mode?
Tell us about your production requirements and we'll configure the ideal Razor6 system for your line — including any ancillary equipment needed for a complete solution.
Industrial inkjet for 24×7 environments
UV cured & aqueous ink compatibility
Tracesci RapidPro VDP software included
Quick return on investment
Full ancillary equipment range available
High-Speed Variable Data Printing for 24×7 Production
Razor6 combines Piezo DOD inkjet technology, Tracesci RapidPro VDP software, online code verification, and ultra-fast PDF printing into one industrial-grade production platform — delivering reliable high-resolution output at speeds up to 150 m/min across packaging, labels, pharma, and security substrates.
