Hyperloop

Slit. Inspect. Print. All in one loop.

High Speed Finishing Solutions

High Speed Finishing Solutions

Four integrated solutions for modern label and packaging production — from variable data printing and inspection to digital slitting and label transfer.

Variable Data Printing Solution

Powered by tracesci VDP software — print barcodes, QR codes, serial numbers, dates, counters, and custom graphics inline at full production speed. Printheads can be combined arbitrarily with multiple documents printed simultaneously for complete traceability...

High Speed Vision Inspection

100% online inspection at up to 250 m/min. Detects scratches, stains, de-ink, foreign particles, colour deviations, and logo errors. Reads 1D/2D/QR and security codes with full OCR/ICV verification and automated inspection report generation...

Automated Digital Slitting

9-blade digitally positioned slitting at up to 150 m/min with automatic blade positioning via HMI — no manual changeover required. Integrated QC defect-removal plate ensures only perfect rolls leave the line...

Dual Rewinder & Web Guide

Dual rewinder with integrated dual web guide (one unit after unwinder, one before slitting) ensures perfect tension-controlled rewinding and precise roll geometry — eliminating edge misalignment at any speed...

Label Transfer Device System

Inline label transfer device enables seamless reel changeover and label repositioning without stopping production, maximising uptime across continuous manufacturing runs in pharma, packaging, and security applications...

Track & Trace Integration

End-to-end serialisation and authentication from the tracesci platform — uniquely identify every item across the supply chain. Supports full product authentication, anti-counterfeiting, and compliance workflows with centrally controlled print management...

Technical Specifications

Technical Specifications

Unwinder · Dual Rewinder · Automated Digital Slitting — 9-blade HMI positioning at up to 200 m/min.

Slitting & Web Handling
Model
Hyperloop 330 / 450
Model Type
Unwinder, Dual Rewinder, Automated Digital Slitting
Web Feed Width
Max 330 mm / 450 mm, Min 20 mm
Slitting Speed
Up to 150 m/min
Subject to substrate type — 9 pcs blade
Running Speed
Up to 200 m/min
Subject to substrate type
Positioning
Blade positioning automatic digitally by HMI
QC Area
Quality Control or defect removal plate
Web Guide & Mechanical
Web Guide
2 units
Max Roll Weight
Approx. 120 kg
Dimensions
2330 × 1300 × 1500 mm
Electrical
220–240 V, 3 KW
Control
Touch Screen Panel
Vision System
H. Resolution
0.15 mm
V. Resolution
0.15 mm
Detection Width
10 – 1500 mm
Top Speed
250 m/min
Point Defect
Area > 0.2 mm²
Streak Defect
Area > 0.1 mm · 5 mm
Registration
H > 0.15 mm | V > 0.25 mm

Built for speed & precision finishing

The Hyperloop is engineered to deliver exceptional throughput at up to 200 m/min without sacrificing slitting accuracy or inspection integrity — even in high-demand continuous production environments across label, packaging, pharma, and security substrates.

  • Suited Best For :

  • Paper & Coated

  • Plastics & PVC

  • Labels & Flexible Packaging

  • Pharma & Healthcare Packaging

  • Secure Substrates

  • Beverage & Food Packaging

  • Cartons & Folding Boxes

Industry Wide Applications

Industry Wide Applications

Complete coverage across every sector

From pharmaceutical serialisation to beverage packaging authentication — configure the Hyperloop for the traceability and quality demands of any production environment.

Food
Food packaging & labelling
Beverage
Bottle & container labels
Packaging
Flexible & rigid packaging
Security
Authentication & anti-counterfeit
Health & Safety
Compliance labelling
Personal Care
Cosmetics & personal products
Chemical
Industrial chemical labelling
Pharmaceutical
Serialisation & track & trace
Automotive
Parts ID & compliance labels
Industrial
Industrial product labelling

Working Environment

Working Environment

Optimised for consistent performance

200 m/min
Max Running Speed

The Hyperloop runs at speeds up to 200 m/min (subject to substrate type), delivering one of the fastest inline slitting and inspection throughputs available for label and packaging converters.

220–240 V / 3 KW
Power Requirements

Standard single-phase 220–240 V supply at 3 KW, keeping installation straightforward across most factory environments without any special electrical infrastructure.

Touch HMI
Intuitive Control

All machine functions — blade positioning, web guide, speed control, and inspection thresholds — managed from a single touch screen panel, reducing training time and eliminating operator error.

Man and woman working together
Get In Touch
Ready to loop into
production mode?

Tell us about your production requirements and we'll configure the ideal Hyperloop system for your line — including VDP software setup, vision inspection calibration, and slitting configuration.

Running speed up to 200 m/min
Web widths 330 mm & 450 mm
100% online vision inspection at 250 m/min
9-blade automated digital slitting via HMI
tracesci VDP — barcodes, QR, serialisation

High-Speed Inspection, Slitting & Variable Data Printing

Hyperloop combines variable data printing, 100% online vision inspection, automated digital slitting, dual rewinding, and label transfer technology into one integrated inline production system — delivering speeds up to 200 m/min for modern label and packaging environments.
